UPG208DNC
HDCNC
Item | Unit | UPG208DNC |
Table size (width * length) | mm | 2400*950 |
Max. grinding workpiece length | mm | 2000 |
Max. bearing weight of table (including suction cup weight) | kg | 2000 |
Table longitudinal (X axis) effective travel | mm | 2000 |
Vertical (Z-axis) distance of the grinding head | mm | 500 |
Transverse movement of the grinding head (Y-axis) distance | mm | 1100 |
Table T-slot dimensions (slot width * slot spacing * slot number) | mm | 28*180*5 |
Gantry spacing | mm | 1200 |
Grinding head spindle motor power | kw | 18.5 |
Grinding wheel size (outer diameter * width * inner hole) | mm | 500*75*203 |
Machine dimensions (L * W * H) | mm | 7300*3200*3000 |
Machine weight | KG | 约17000 About 17000 |
Total machine motor power | KW | 约50 About 50 |
Machining workpiece surface roughness | um | ≤Ra0.1 |
Purpose and structural characteristics of machine tools
PurpoThis product is a fixed beam gantry surface grinder, and the machine tool adopts a gantry layout, consisting of a closed rigid frame structure composed of double columns, crossbeams, and bed body. The worktable moves longitudinally along the bed guide rail, and the worktable guide rail adopts a static pressure guide rail.
The crossbeam is equipped with a linear guide rail, which has a horizontal sliding plate that can move laterally along the crossbeam. Vertical skateboards are also equipped with linear guides, which can perform vertical feed motion along horizontal skateboards. There is a horizontal peripheral grinding head installed on the vertical skateboard. Having sufficient static, dynamic, and thermal stiffness and stable output, advanced technology is adopted to ensure that the system has good dynamic quality.
The selected servo drive system has high precision, reliability, and fast response speed of the execution components. The horizontal peripheral grinding head is a box structure, and its internal spindle support adopts a dynamic and static pressure bearing structure. Static and dynamic pressure bearings have the advantages of high motion accuracy, no wear, long service life, low starting power, high load-bearing capacity at high speeds, and good vibration resistance compared to static pressure bearings.
They are the preferred bearings for grinding machine spindles. Mainly used in the processing of precision parts for new energy vehicles, new energy materials, aviation, and aerospace.
